Single daylight throughfeed press lines
PRODUCT DATA SHEET
Single daylight throughfeed press lines
Ideal for finishing wood-based materials with veneers
As a single-level version, Wemhöner throughfeed press lines are ideal for the finishing of wood-based panels with veneers.
From the entry-level model to a fully automated production line, the systems offer maximum flexibility — with selectable standard modules or individually engineered solutions.
Precise workpiece transport within the press level is ensured by linearly controlled belt systems. Cylinders positioned above the press plates provide uniform pressure distribution of up to 200 N/cm².
Fluid media such as thermal oil or hot water heat the press plates to temperatures of up to 130°C.
A wide range of configuration options
Single daylight throughfeed press lines
TECHNICAL DATA
APPLICATION
Single-sided from the top
LENGTH OF HEATING PLATEN
up to 16,0 m
WIDTH OF HEATING PLATEN
up to 3,2 m
1 – 3 carrier boards
3,2 – 50 mm
SPEC. PRESS PRESSURE
Up to 200 N/cm², higher pressures available on reques
OPERATION MODE
variabel
Adhesive system
manually or automatically
Adhesive system
PVAc adhesive or urea resin glue; other systems on request
CAPACITY
Cycle time: 25–90 sec.
APPLICATION
Finishing of flat wood-based panels and cut-to-size pieces in throughfeed operation. Pressing of MDF, particleboard, thin boards, etc. with veneers, finish foils, HPL, CPL and other materials.
Showcase
OUR CUSTOMERS' PRODUCTS
Application examples Multi-stage continuous presses
furniture elements
Furniture panels
flooring
parquet flooring
interior doors
panels
